Audi A4 B5 (1994-1999) horn button Wiring diagram

This page shows the only wiring diagram for the component.horn button, which is found in the car Audi A4 B5 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram horn button (1 of 1)

Wiring diagram horn button for Audi A4 B5 (1994-1999)

Get access

BLK WIRE BRN WIRE CENTRAL ELECTRIC PANEL DUAL HORN RELAY FUSE 240 FUSE PANEL HIGH NOTE HORN HORN BUTTON HOT AT ALL TIMES IGNITION SWITCH LIGHT SWITCH LOAD REDUCTION RELAY LOW NOTE HORN OFF RED WIRE WHT WIRE YEL WIRE

Go to component: -> Horn circuit -> HORN BUTTON
