Audi A4 B5 (1994-1999) driver seat backrest adjusting motor Wiring diagram

This page shows the only wiring diagram for the component.driver seat backrest adjusting motor, which is found in the car Audi A4 B5 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver seat backrest adjusting motor (1 of 1)

Wiring diagram driver seat backrest adjusting motor for Audi A4 B5 (1994-1999)

Get access

BACK- REST BLK WIRE BLU WIRE BRN WIRE CIRCUIT BREAKER 44 DRIVER SEAT BACKREST ADJUSTING MOTOR DRIVER SEAT FORE/AFT ADJUSTING MOTOR DRIVER SEAT FRONT HEIGHT ADJUSTING MOTOR DRIVER SEAT REAR HEIGHT ADJUSTING MOTOR DRIVER SEAT SWITCH FORE/ AFT FRONT HEIGHT REAR HEIGHT FUSE PANEL GRN WIRE HOT AT ALL TIMES RED WIRE WHT WIRE YEL WIRE

Go to component: -> Left power seat circuit -> DRIVER SEAT BACKREST ADJUSTING MOTOR
