Audi A4 B5 (1994-1999) driver backrest heat element Wiring diagram

This page shows the only wiring diagram for the component.driver backrest heat element, which is found in the car Audi A4 B5 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver backrest heat element (1 of 1)

Wiring diagram driver backrest heat element for Audi A4 B5 (1994-1999)

Get access

BLK WIRE BLU WIRE BRN WIRE DRIVER BACKREST HEAT ELEMENT DRIVER SEAT HEAT REGULATING SWITCH DRIVER SEAT TEMPER- ATURE SENSOR DRIVER SEAT HEAT ELEMENT FUSE 244 FUSE 5 FUSE PANEL GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START NCA WIRE PASSENGER BACKREST HEAT ELEMENT PASSENGER SEAT HEAT ELEMENT PASSENGER SEAT HEAT REGULATING SWITCH PASSENGER SEAT TEMPER- ATURE SENSOR RED WIRE SOLID STATE WHT WIRE YEL WIRE

Go to component: -> Heated seats circuit -> DRIVER BACKREST HEAT ELEMENT
