Multi contour seat circuit, w/ power seat adjustment for Audi A4 Allroad Quattro B9 facelift (2019-2024)

BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER MULTI- CONTOUR SEAT CONTROL MODULE DRIVER MULTI-CONTOUR SEAT COMPRESSOR DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT SWITCH MODULE DRIVER SIDE MASSAGE FUNCTION BUTTON FUSE 3 FUSE PANEL 2 FUSE PANEL B GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES LEFT FRONT SEAT COUPLING STATION RED/BLK WIRE RED/WHT WIRE RELAY & FUSE CARRIER 1 VIO/WHT WIRE YEL/BLK WIRE YEL/WHT WIRE

BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER MASSAGE FUNCTION BUTTON FRONT PASSENGER MULTI-CONTOUR SEAT COMPRESSOR FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT SWITCH MODULE FUSE 3 FUSE PANEL 3 FUSE PANEL F GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES RED/BLK WIRE RED/WHT WIRE RELAY & FUSE CARRIER 2 RIGHT FRONT SEAT COUPLING STATION VIO/WHT WIRE YEL/WHT WIRE
