Access/start circuit for Audi A3 8Y (2020-2024)

ACCESS/START AUTHORIZATION CONTROL MODULE BLK WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/BLU WIRE BURGLARY PROTECTION CONTROL MODULE 2 BURGLARY PROTECTION CONTROL MODULE 3 BURGLARY PROTECTION CONTROL MODULE 4 COMPUTER DATA LINES SYSTEM DRIVER EXTERIOR DOOR HANDLE FRONT PASSENGER EXTERIOR DOOR HANDLE FUSE 18 FUSE PANEL C GRN WIRE GRY/BLU WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT ACCESS/START AUTHORIZATION ANTENNA LEFT FRONT DOOR COUPLING POINT LEFT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA NEAR FIELD COMMUNICATION ANTENNA NEAR FIELD COMMUNICATION CONTROL MODULE ORG/BRN WIRE RED WIRE RIGHT ACCESS/START AUTHORIZATION ANTENNA RIGHT FRONT DOOR COUPLING POINT VIO WIRE VIO/YEL WIRE W/O NEAR FIELD COMMUNICATION WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

ACCESS/START AUTHORIZATION BUTTON (UNDER FRONT CENTER CONSOLE) BLK WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BURGLARY PROTECTION CONTROL MODULE 5 COMPUTER DATA LINES SYSTEM ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE FUSE 6 FUSE PANEL C GRN WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT REAR DOOR COUPLING POINT LEFT REAR EXTERIOR DOOR HANDLE MOBILE DEVICE CHARGER 1 NEAR FIELD COMMUNICATION ANTENNA 2 NEAR FIELD COMMUNICATION CONTROL MODULE 2 ORG/BRN WIRE RED WIRE RED/BLU WIRE RIGHT REAR DOOR COUPLING POINT RIGHT REAR EXTERIOR DOOR HANDLE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 1 VIO/YEL WIRE WHT WIRE WHT/RED WIRE YEL WIRE
