Audi A3 8V facelift (2016-2020) driver window lowering microswitch Wiring diagram
This page shows the only wiring diagram for the component.driver window lowering microswitch, which is found in the car Audi A3 8V facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver window lowering microswitch (1 of 1)
4 DOOR
4 DOOR 5 DOOR
5 DOOR
BLU/BLK WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CENTRAL WINDOW REGULATOR SWITCH
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER POWER WINDOW BUTTON
DRIVER SIDE REAR CHILD SAFETY LOCK BUTTON
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR POWER WINDOW BUTTON
DRIVER SIDE REAR WINDOW REGULATOR MOTOR
DRIVER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE
DRIVER WINDOW LOWERING MICROSWITCH
DRIVER WINDOW REGULATOR MOTOR
FRONT PASSENGER POWER WINDOW BUTTON
FUSE 25
FUSE 39
FUSE PANEL C
GRN/BLK WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER SIDE REAR CHILD SAFETY LOCK BUTTON
PASSENGER SIDE REAR POWER WINDOW BUTTON
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
SWITCH ILLUMINATION
VIO/GRY WIRE
W/ AUXILIARY LAMPS
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power windows circuit (1 of 2) -> DRIVER WINDOW LOWERING MICROSWITCH
