Audi A3 8V facelift (2016-2020) driver side rear door control module Wiring diagrams

ACCESS/START AUTHORIZATION CONTROL MODULE BLK/VIO WIRE BLK/YEL WIRE BRN WIRE BRN/YEL WIRE CLIMATRONIC CONTROL MODULE CONVERTIBLE TOP CONTROL MODULE DIAGNOSTIC CONNECTOR DIGITAL SOUND SYSTEM CONTROL MODULE DRIVER DOOR CONTROL MODULE DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FRONT PASSENGER DOOR CONTROL MODULE FUSE 35 FUSE 5 FUSE 8 FUSE PANEL C GRN/VIO WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER (W/ MULTI-FUNCTION DISPLAY) INSTRUMENT CLUSTER (W/O MULTI-FUNCTION DISPLAY) ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/RED WIRE ORG/VIO WIRE PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE WINDOW REGULATOR MOTOR CONTROL MODULE RED/BLU WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE TV TUNER VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE W/O HEATED STEERING WHEEL W/ HEATED STEERING WHEEL W/O START/STOP SYSTEM

4 DOOR 5 DOOR BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/YEL WIRE DRIVER SIDE REAR CENTRAL LOCKING LOCK UNIT DRIVER SIDE REAR DOOR AMBIENT LIGHT LAMP DRIVER SIDE REAR DOOR CONTACT SWITCH DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR ENTRY LAMP DRIVER SIDE REAR INTERIOR DOOR HANDLE ILLUMINATION BULB DRIVER SIDE REAR INTERIOR LOCKING BUTTON DRIVER SIDE REAR POWER WINDOW BUTTON GRN WIRE GRN/WHT WIRE GRY WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FOOTWELL LAMP LEFT REAR FOOTWELL LAMP LIGHT SWITCH RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FOOTWELL LAMP RIGHT REAR FOOTWELL LAMP VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/YEL WIRE W/ AUXILIARY LAMPS W/ CHILD SAFETY LOCK W/O CHILD SAFETY LOCK WHT WIRE

BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE DRIVER SIDE REAR CENTRAL LOCKING LOCK UNIT DRIVER SIDE REAR CENTRAL LOCKING SYSTEM ACTUATOR DRIVER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR DRIVER SIDE REAR CHILD SAFETY LOCK MOTOR DRIVER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR DRIVER SIDE REAR DOOR CONTACT SWITCH DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR INTERIOR LOCKING BUTTON FUSE 25 FUSE 39 FUSE PANEL C GRN/VIO WIRE GRN/WHT WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT REAR CHILD SAFETY LOCK CONTACT SWITCH PASSENGER SIDE REAR CENTRAL LOCKING LOCK UNIT PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM ACTUATOR PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR PASSENGER SIDE REAR CHILD SAFETY LOCK MOTOR PASSENGER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR PASSENGER SIDE REAR DOOR CONTACT SWITCH PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR INTERIOR LOCKING BUTTON RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT REAR CHILD SAFETY LOCK CONTACT SWITCH VIO WIRE VIO/RED WIRE W/ CHILD SAFETY LOCK W/ CHILD SAFETY LOCK W/O CHILD SAFETY LOCK WHT/BLU WIRE YEL WIRE

4 DOOR 4 DOOR 5 DOOR 5 DOOR BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CIGARETTE LIGHTER CIGARETTE LIGHTER ILLUMINATION BULB COURTESY LAMPS CIRCUIT DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR INTERIOR LOCKING BUTTON DRIVER SIDE REAR POWER WINDOW BUTTON FUSE 25 FUSE 39 FUSE PANEL C GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES MIRROR ADJUSTING SWITCH POWER SUNROOF CONTROL MODULE REAR LID UNLOCK SWITCH RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE SELECTOR LEVER SOCKET ILLUMINATION BULB SUNROOF BUTTON VIO/GRY WIRE VIO/YEL WIRE W/ AUXILIARY LAMPS WHT WIRE

2.0L TURBO ACCESS/START AUTHORIZATION CONTROL MODULE AIR QUALITY SENSOR, HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR REAR VIEW MIRROR BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU/WHT WIRE CENTER SWITCH MODULE CONVERTIBLE TOP CONTROL MODULE CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE DIAGNOSTIC CONNECTOR DRIVER DOOR CONTROL MODULE DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE ELECTRIC DRIVE POWER, CONTROL ELECTRONICS ENGINE SOUND GENERATOR CONTROL MODULE EXCEPT HYBRID FROM FUSE 33 (DIAGRAM 6 OF 7) FROM FUSE 45 (DIAGRAM 6 OF 7) FUSE 19 FUSE 23 FUSE 25 FUSE 28 FUSE 35 FUSE 36 FUSE 37 FUSE 47 FUSE 48 FUSE 49 FUSE PANEL C GRN/BLU WIRE HYBRID BATTERY UNIT LEFT HEADLAMP POWER OUTPUT MODULE LEFT FRONT HEADLAMP LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT FRONT HEADLAMP POWER SUNROOF CONTROL MODULE REAR WINDOW WIPER MOTOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT HEADLAMP POWER OUTPUT MODULE RIGHT FRONT HEADLAMP RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT FRONT HEADLAMP SEDAN, SPORTBACK TO ELECTRONICS BOX (DIAGRAM 4 OF 7) TO FUSE 24 (DIAGRAM 2 OF 7) VIO/GRN WIRE W/ ELECTRICALLY OPERATED CHILD LOCK WHT/RED WIRE

BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE DRIVER SIDE REAR CENTRAL LOCKING LOCK UNIT DRIVER SIDE REAR CENTRAL LOCKING SYSTEM ACTUATOR DRIVER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR DRIVER SIDE REAR CHILD SAFETY LOCK MOTOR DRIVER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR DRIVER SIDE REAR DOOR CONTACT SWITCH DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR INTERIOR LOCKING BUTTON FUSE 25 FUSE 39 FUSE PANEL C GRN/VIO WIRE GRN/WHT WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT REAR CHILD SAFETY LOCK CONTACT SWITCH PASSENGER SIDE REAR CENTRAL LOCKING LOCK UNIT PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM ACTUATOR PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR PASSENGER SIDE REAR CHILD SAFETY LOCK MOTOR PASSENGER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR PASSENGER SIDE REAR DOOR CONTACT SWITCH PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR INTERIOR LOCKING BUTTON RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT REAR CHILD SAFETY LOCK CONTACT SWITCH VIO WIRE VIO/RED WIRE W/ CHILD SAFETY LOCK W/ CHILD SAFETY LOCK W/O CHILD SAFETY LOCK WHT/BLU WIRE YEL WIRE

4 DOOR 4 DOOR 5 DOOR 5 DOOR BLU/BLK WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CENTRAL WINDOW REGULATOR SWITCH DRIVER DOOR CONTROL MODULE DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER POWER WINDOW BUTTON DRIVER SIDE REAR CHILD SAFETY LOCK BUTTON DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR POWER WINDOW BUTTON DRIVER SIDE REAR WINDOW REGULATOR MOTOR DRIVER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE DRIVER WINDOW LOWERING MICROSWITCH DRIVER WINDOW REGULATOR MOTOR FRONT PASSENGER POWER WINDOW BUTTON FUSE 25 FUSE 39 FUSE PANEL C GRN/BLK WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE REAR CHILD SAFETY LOCK BUTTON PASSENGER SIDE REAR POWER WINDOW BUTTON RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SWITCH ILLUMINATION VIO/GRY WIRE W/ AUXILIARY LAMPS YEL WIRE YEL/GRN WIRE YEL/RED WIRE
