Audi A3 8V facelift (2016-2020) battery interrupt igniter Wiring diagram
This page shows the only wiring diagram for the component.battery interrupt igniter, which is found in the car Audi A3 8V facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery interrupt igniter (1 of 1)
2.0L TURBO
2.0L TURBO, 1.4L TURBO
AIR BAG CONTROL MODULE
BATTERY
BATTERY INTERRUPT IGNITER
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BLK/YEL WIRE
BLU/GRN WIRE
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
ELECTRONIC DAMPING CONTROL MODULE
ELECTRONICS BOX)
FRESH AIR BLOWER CONTROL MODULE
FROM ELECTRONICS BOX (DIAGRAM 5 OF 7)
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 2
FUSE 3
FUSE 4
FUSE 41
FUSE 42
FUSE 5
FUSE 52
FUSE PANEL A
FUSE PANEL C
FUSES (ON FUSE PANEL)
GENERATOR, VOLTAGE REGULATOR
GRN/RED WIRE
GRY WIRE
GRY/YEL WIRE
HYBRID EXCEPT HYBRID 2.0L TURBO, 1.4L TURBO 2.5L TURBO
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE
LUGGAGE COMPARTMENT MAIN FUSE PANEL
N/A
NCA WIRE
NECK HEATING RELAY
POWER STEERING CONTROL MODULE
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE
SAFETY FUSE 1
SAFETY FUSE 2
SAFETY FUSE 3
STARTER
TERMINAL 30 WIRE JUNCTION 2
TO ELECTRONICS BOX (DIAGRAM 2 OF 7)
TO FUSE 5 (DIAGRAM 2 OF 7)
TO FUSE 9 (DIAGRAM 3 OF 7)
TO FUSE PANEL C (DIAGRAM 6 OF 7)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/RED WIRE
VIO/WHT WIRE
Go to component -> Power distribution circuit (1 of 7) -> BATTERY INTERRUPT IGNITER
