Audi A3 8P facelift (2004-2008) spiral spring Wiring diagram
This page shows the only wiring diagram for the component.spiral spring, which is found in the car Audi A3 8P facelift (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spiral spring (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
CRUISE CONTROL SYSTEM
DRIVER'S AIRBAG IGNITER
DRIVER'S AIRBAG IGNITER 2
FUSE HOLDER FUSE 13
GRY WIRE
HOT AT ALL TIMES
IGNITION/STARTER SWITCH
LEFT MULTI-FUNCTION BUTTONS
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT MULTI-FUNCTION BUTTONS
SHORTING CONTACT
SIGNAL HORN ACTIVATION
SPIRAL SPRING
STEERING ANGLE SENSOR
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
STEERING WHEEL CONTROL UNIT
SUPPLEMENTAL RESTRAINTS SYSTEM
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSMISSIONS SYSTEM COMPUTER DATA LINES SYSTEM
TURN SIGNAL SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
WINDSHIELD WIPER/ WASHER SWITCH
YEL WIRE
YEL/BLU WIRE
