Audi A3 8P facelift (2004-2008) rear/center central locking switch wiring diagram
This page shows the only wiring diagram for the component.rear/center central locking switch, which is found in the car Audi A3 8P facelift (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear/center central locking switch wiring diagram (1 of 1)
ASHTRAY LIGHT
ASR/ESP BUTTON
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
CUP HOLDER ILLUMINATION
FRONT INTERIOR LIGHT ASSEMBLY
GARAGE DOOR OPENER CONTROL HEAD
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/YEL WIRE
LIGHT SWITCH
ORG/ WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR INTERIOR LIGHT ASSEMBLY
REAR/CENTER CENTRAL LOCKING SWITCH
RED WIRE
SOCKET
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (UNDER STEERING COLUMN)
STORAGE COMPARTMENT ILLUMINATION
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH)
WHT WIRE
YEL/BLU WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> REAR/CENTER CENTRAL LOCKING SWITCH
