Audi A3 8P facelift (2004-2008) left temperature flap potentiometer/ actuator Wiring diagram

This page shows the only wiring diagram for the component.left temperature flap potentiometer/ actuator, which is found in the car Audi A3 8P facelift (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left temperature flap potentiometer/ actuator (1 of 1)

Wiring diagram left temperature flap potentiometer/ actuator for Audi A3 8P facelift (2004-2008)

Get access

A/C COMPRESSOR REGULATOR VALVE AIR QUALITY SENSOR BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE CLIMATRONIC CONTROL MODULE EVAPORATOR VENT TEMPERATURE SENSOR FRESH AIR BLOWER FRESH AIR INTAKE DUCT TEMPERATURE SENSOR FUSE 16 FUSE 22 FUSE 37 FUSE 4 FUSE 46 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HIGH PRESSURE SENSOR HOT AT ALL TIMES LEFT FOOTWELL VENT TEMPERATURE SENSOR LEFT TEMPERATURE FLAP POTENTIOMETER/ ACTUATOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOOTWELL VENT TEMPERATURE SENSOR SEATS SYSTEM WHT/BLU WIRE

Go to component: -> Automatic a/c circuit (1 of 3) -> LEFT TEMPERATURE FLAP POTENTIOMETER/ ACTUATOR
