Audi A3 8P facelift (2004-2008) interior lights, door locks,, mirrors system wiring diagram
This page shows the only wiring diagram for the component.interior lights, door locks,, mirrors system, which is found in the car Audi A3 8P facelift (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
interior lights, door locks,, mirrors system wiring diagram (1 of 1)
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR POWER WINDOW MASTER SWITCH
DRIVER'S WINDOW REGULATOR MOTOR
FRONT PASSENGER'S WINDOW REGULATOR MOTOR
FUSE 12
FUSE 19
FUSE 23
FUSE 28
FUSE 38
FUSE PANEL C
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS, DOOR LOCKS,, MIRRORS SYSTEM
LEFT FRONT WINDOW REGULATOR SWITCH
LEFT PASSENGER'S REAR REGULATOR MOTOR
LEFT REAR WINDOW REGULATOR SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
REAR WINDOW REGULATOR SWITCH
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT WINDOW REGULATOR SWITCH
RIGHT REAR WINDOW REGULATOR MOTOR
RIGHT REAR WINDOW REGULATOR SWITCH
Go to component -> Power windows circuit -> INTERIOR LIGHTS, DOOR LOCKS,, MIRRORS SYSTEM
