Audi A3 8P facelift (2004-2008) front passenger's airbag igniter Wiring diagram
This page shows the only wiring diagram for the component.front passenger's airbag igniter, which is found in the car Audi A3 8P facelift (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's airbag igniter (1 of 1)
AIR BAG SPIRAL SPRING/ RETURN SPRING (W/SLIP RING)
AIRBAG CONTROL MODULE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG IGNITER
DRIVER'S AIR BAG IGNITER 2
DRIVER'S HEAD CURTAIN AIRBAG IGNITER
DRIVER'S SIDE AIRBAG IGNITER
FRONT PASSENGER'S AIRBAG DISABLE INDICATOR LAMP
FRONT PASSENGER'S AIRBAG IGNITER
FUSE 29
FUSE 5
FUSE PANEL C
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITER 1
IGNITER 2
NCA WIRE
ORG/ WIRE
PPL
REAR PASSENGER'S SIDE AIRBAG (DRIVER'S SIDE) IGNITER
REAR PASSENGER'S SIDE AIRBAG (FRONT PASSENGER'S SIDE) IGNITER
RED WIRE
SHORT CIRCUIT BRIDGE (IT SHORTS THE PINS WHEN CONNECTOR IS UNPLUGGED)
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
WHT WIRE
YEL WIRE
YEL/PPL WIRE
Go to component: -> Supplemental restraints circuit (1 of 3) -> FRONT PASSENGER'S AIRBAG IGNITER
