Navigation circuit, with rns-e with bose for Audi A3 8P facelift 2 (2008-2013)

ANTENNA BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CD CHANGER OR IPOD BASEPLATE OR USB BASEPLATE (IF EQUIPPED) COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM FUSE 18 FUSE 9 FUSE PANEL B (INTEGRATED IN ENGINE COMPT E-BOX) FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE OPERATING ELECTRONICS, NAVIGATION CONTROL MODULE ORG/BRN WIRE ORG/VIO WIRE POWER DISTRIBUTION SYSTEM REAR WINDOW DEFOGGER W/ WINDOW ANTENNA (W/ CENTRAL LOCKING, ANTI-THEFT ALARM) RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SATELLITE RADIO (IF EQUIPPED) (LEFT SIDE OF LUGGAGE COMPT) TELEPHONE TRANSCEIVER (W/ CELLULAR TELEPHONE) VIO WIRE VIO/GRY WIRE VIO/RED WIRE W/ SATELLITE RADIO W/O SATELLITE RADIO WHT WIRE WHT/YEL WIRE YEL WIRE

ANTENNA AMPLIFIER (TOP LEFT SIDE OF CARGO AREA LID) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/YEL WIRE DEFOGGER SYSTEM FUSE 10 FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES INSIDE MICROPHONE LEFT ANTENNA MODULE (LEFT SIDE OF LUGGAGE COMPT LID) LEFT FRONT MID-BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MIDRANGE SPEAKER LEFT REAR TREBLE SPEAKER NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MID-BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR MIDRANGE SPEAKER RIGHT REAR TREBLE SPEAKER WHT WIRE WHT/BLK WIRE YEL WIRE

AMPLIFIER (RIGHT SIDE OF LUGGAGE COMPT) BASS SPEAKER BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER MID/HIGH RANGE SPEAKER COMPUTER DATA LINES SYSTEM EXTERNAL AUDIO SOURCE CONNECTION GRN WIRE GRY WIRE OPERATING ELECTRONICS, NAVIGATION CONTROL MODULE ORG/BRN WIRE ORG/VIO WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE VIO WIRE W/ AUDI MUSIC INTERFACE W/O AUDI MUSIC INTERFACE WHT WIRE WHT/BLK WIRE YEL WIRE
