Audi A3 8P facelift 2 (2008-2013) vehicle positioning system interface control module Wiring diagram
This page shows the only wiring diagram for the component.vehicle positioning system interface control module, which is found in the car Audi A3 8P facelift 2 (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle positioning system interface control module (1 of 1)
3 20 20 PIN CONNECTOR (NOT USED)
A/C CONTROL MODULE
AIR BAG CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
ALARM HORN (W/ ANTI-THEFT ALARM SYSTEM) (IN RIGHT FRONT WHEELWELL)
AMPLIFIER/ WOOFER
AUXILIARY HEATER CONTROL MODULE
BLU/YEL WIRE
CLIMATRONIC CONTROL MODULE
INCLINATION/ ANTI-THEFT CONTROL MODULE (W/ ANTI-THEFT ALARM SYSTEM)
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR MONITORING SENSOR (W/ ANTI-THEFT ALARM SYSTEM)
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
RADIO (W/ RADIO GENERATION 2 PLUS)
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (UNDER STEERING COLUMN)
TIRE PRESSURE MONITORING CONTROL MODULE (BEHIND GLOVE COMPT)
TOWING RECOGNITION CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH)
VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
VIO/WHT WIRE
W/ HILL HOLD ASSIST
Go to component: -> Computer data lines circuit (2 of 2) -> VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE
