Audi A3 8P facelift 2 (2008-2013) trunk lid alarm switch Wiring diagrams

This page contains all the electrical diagrams for the component. trunk lid alarm switch, in which he is found in the car Audi A3 8P facelift 2 (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram trunk lid alarm switch (1 of 2)

Wiring diagram trunk lid alarm switch for Audi A3 8P facelift 2 (2008-2013)

Get access

3 DOOR 5 DOOR ALARM HORN (IF EQUIPPED) (IN RIGHT FRONT WHEELWELL) ANTENNA AMPLIFIER 2 BLK WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA COMPUTER DATA LINES SYSTEM FRONT HOOD SWITCH (BASE OF ENGINE COMPT HOOD LATCH) FUSE 17 FUSE PANEL C GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR CENTRAL LOCKING LOCK UNIT NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PARKING BRAKE CONTACT SWITCH PASSENGER COMPARTMENT MONITORING, ALARM SYSTEM OFF SWITCHES REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR WINDOW GLASS BREAKAGE SENSOR (W/ ANTI-THEFT ALARM) REAR/CENTER CENTRAL LOCKING SWITCH RED GRN/ WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE TRUNK LID ALARM SWITCH TRUNK LID ALARM SWITCH, REAR LID CENTRAL LOCKING SYSTEM MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH) VIO/BLU WIRE VIO/WHT WIRE W/O NAVIGATION W/ NAVIGATION WHT WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Anti-theft circuit (2 of 2) -> TRUNK LID ALARM SWITCH

Wiring diagram trunk lid alarm switch (2 of 2)

Wiring diagram trunk lid alarm switch for Audi A3 8P facelift 2 (2008-2013)

Get access

3 DOOR 5 DOOR ALARM HORN (IF EQUIPPED) (IN RIGHT FRONT WHEELWELL) ANTENNA AMPLIFIER 2 BLK WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA COMPUTER DATA LINES SYSTEM FRONT HOOD SWITCH (BASE OF ENGINE COMPT HOOD LATCH) FUSE 17 FUSE PANEL C GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR CENTRAL LOCKING LOCK UNIT NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PARKING BRAKE CONTACT SWITCH PASSENGER COMPARTMENT MONITORING, ALARM SYSTEM OFF SWITCHES REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR WINDOW GLASS BREAKAGE SENSOR (W/ ANTI-THEFT ALARM) REAR/CENTER CENTRAL LOCKING SWITCH RED GRN/ WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE TRUNK LID ALARM SWITCH TRUNK LID ALARM SWITCH, REAR LID CENTRAL LOCKING SYSTEM MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH) VIO/BLU WIRE VIO/WHT WIRE W/O NAVIGATION W/ NAVIGATION WHT WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Power door locks circuit (2 of 2) -> TRUNK LID ALARM SWITCH
