Audi A3 8P facelift 2 (2008-2013) right front seat temperature sensor Wiring diagrams

This page contains all the electrical diagrams for the component. right front seat temperature sensor, in which he is found in the car Audi A3 8P facelift 2 (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right front seat temperature sensor (1 of 2)

Wiring diagram right front seat temperature sensor for Audi A3 8P facelift 2 (2008-2013)

Get access

AIR CONDITIONING SYSTEM BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT FRONT PASSENGER BACKREST HEATING ELEMENT FUSE 37 FUSE PANEL C GRN WIRE HEATING ELEMENT HOT AT ALL TIMES LEFT FRONT HEATED SEAT LEFT FRONT SEAT TEMPERATURE SENSOR NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/YEL WIRE RIGHT FRONT HEATED SEAT RIGHT FRONT SEAT TEMPERATURE SENSOR SIDE BOLSTER HEATER SIDE BOLSTER HEATER 2 WHT WIRE YEL WIRE YEL/BLU WIRE

Go to component: -> Heated seats circuit, with power seats -> RIGHT FRONT SEAT TEMPERATURE SENSOR

Wiring diagram right front seat temperature sensor (2 of 2)

Wiring diagram right front seat temperature sensor for Audi A3 8P facelift 2 (2008-2013)

Get access

AIR CONDITIONING SYSTEM BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT FRONT PASSENGER'S BACKREST HEATING ELEMENT FUSE 37 FUSE PANEL C GRN WIRE HEATING ELEMENT HOT AT ALL TIMES LEFT FRONT HEATED SEAT LEFT FRONT SEAT TEMPERATURE SENSOR ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/YEL WIRE RIGHT FRONT HEATED SEAT RIGHT FRONT SEAT TEMPERATURE SENSOR SIDE BOLSTER HEATER SIDE BOLSTER HEATER 2 WHT WIRE YEL WIRE YEL/BLU WIRE

Go to component: -> Heated seats circuit, with sport seats -> RIGHT FRONT SEAT TEMPERATURE SENSOR
