Audi A3 8P facelift 2 (2008-2013) right front left rear window window regulator regulator switch switch Wiring diagram
This page shows the only wiring diagram for the component.right front left rear window window regulator regulator switch switch, which is found in the car Audi A3 8P facelift 2 (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front left rear window window regulator regulator switch switch (1 of 1)
BLU/ BRN WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL WINDOW REGULATOR SWITCH (IN DRIVER DOOR)
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR POWER WINDOW MASTER SWITCH
DRIVER'S WINDOW REGULATOR MOTOR
FRONT PASSENGER WINDOW REGULATOR 26 15 21 MOTOR
FUSE 12
FUSE 13
FUSE 23
FUSE 28
FUSE 38
FUSE PANEL C
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT FRONT WINDOW REGULATOR SWITCH
LEFT REAR 22 8 4 WINDOW REGULATOR MOTOR
LEFT REAR DOOR WINDOW SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER DOOR WINDOW REGULATOR SWITCH
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT LEFT REAR WINDOW WINDOW REGULATOR REGULATOR SWITCH SWITCH
RIGHT REAR DOOR WINDOW SWITCH
RIGHT REAR WINDOW 22 8 4 REGULATOR MOTOR
RIGHT REAR WINDOW REGULATOR SWITCH
VIO/WHT WIRE
W/ PASSENGER COMPARTMENT MONITORING
W/O PASSENGER COMPARTMENT MONITORING
