Audi A3 8P facelift 2 (2008-2013) light recognition 3 4 5 8 3 4 5 sensor Wiring diagram

This page shows the only wiring diagram for the component.light recognition 3 4 5 8 3 4 5 sensor, which is found in the car Audi A3 8P facelift 2 (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram light recognition 3 4 5 8 3 4 5 sensor (1 of 1)

Wiring diagram light recognition 3 4 5 8 3 4 5 sensor for Audi A3 8P facelift 2 (2008-2013)

Get access

AUTOMATIC DAY/NIGHT INTERIOR MIRROR BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE PANEL C FUSE 4 HOT AT ALL TIMES FUSE FUSE PANEL B (INTEGRATED IN ENGINE COMPARTMENT E-BOX) LIGHT RECOGNITION 3 4 5 8 3 4 5 SENSOR ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POWER SUPPLY RELAY 2 (TERMINAL 15) (ON RELAY CARRIER) RED WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH) VIO WIRE VIO/BLK WIRE W/ AUTOMATIC HIGH BEAM CONTROL W/O AUTOMATIC HIGH BEAM CONTROL YEL WIRE

Go to component: -> Automatic day/night mirror circuit -> LIGHT RECOGNITION 3 4 5 8 3 4 5 SENSOR
