Audi A3 8P facelift 2 (2008-2013) hot at all times fuse panel c fuse 14 Wiring diagrams

This page contains all the electrical diagrams for the component. hot at all times fuse panel c fuse 14, in which he is found in the car Audi A3 8P facelift 2 (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram hot at all times fuse panel c fuse 14 (1 of 2)

Wiring diagram hot at all times fuse panel c fuse 14 for Audi A3 8P facelift 2 (2008-2013)

Get access

A/T HYDRAULIC PRESSURE SENSORS A/T PRESSURE REGULATING VALVES AIR BAG SPIRAL SPRING/RETURN SPRING (W/ SLIP RING) (BEHIND STEERING WHEEL) BLK WIRE BLK/GRY WIRE BRN WIRE CLUTCH OIL TEMPERATURE SENSOR, TRANSMISSION INPUT SPEED (RPM) SENSOR COMPUTER DATA LINES SYSTEM DIRECT SHIFT GEARBOX (DSG) MECHATRONIC (ON TRANSMISSION HOUSING) DRIVESHAFT SPEED SENSOR 1 DRIVESHAFT SPEED SENSOR 2 FUSE FUSE PANEL B (INTEGRATED IN ENGINE COMPT E-BOX) GEAR POSITION DISTANCE SENSORS GRY WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL C FUSE 14 HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SELECTOR LEVER SCALE ILLUMINATION SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (LEFT SIDE OF SELECTOR LEVER BASE) SELECTOR LEVER SWITCH SELECTOR LEVER TRANSMISSION RANGE (TR) POSITION DISPLAY UNIT SHIFT LOCK SOLENOID, SELECTOR LEVER SOLENOID VALVES STEERING COLUMN ELECTRONICS SYSTEM CONTROL MODULE (UNDER STEERING COLUMN) STEERING WHEEL CONTROL MODULE TEMPERATURE SENSOR TIPTRONIC DOWNSHIFT TIPTRONIC UPSHIFT BUTTON BUTTON TIPTRONIC SWITCH TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION OUTPUT SPEED (RPM) SENSOR TRANSMISSION OUTPUT SPEED (RPM) SENSOR 2 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH) VIO WIRE VIO/BLK WIRE WHT WIRE YEL WIRE YEL/BLU WIRE

Go to component: -> A/t circuit -> HOT AT ALL TIMES FUSE PANEL C FUSE 14

Wiring diagram hot at all times fuse panel c fuse 14 (2 of 2)

Wiring diagram hot at all times fuse panel c fuse 14 for Audi A3 8P facelift 2 (2008-2013)

Get access

BLK WIRE BLK/GRY WIRE BLK/YEL WIRE BRN WIRE CBFA COMPUTER DATA LINES SYSTEM DIRECT SHIFT GEARBOX (DSG) MECHATRONIC (ON TRANSMISSION HOUSING) ENGINE CONTROL MODULE (ECM) (REAR OF ENGINE COMPT) ENGINE CONTROLS SYSTEM EXCEPT CBFA FUSE 2 GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES FUSE PANEL C FUSE 14 HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED NCA WIRE ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/VIO WIRE SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (LEFT SIDE OF SELECTOR LEVER BASE) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH) VIO WIRE VIO/BLK WIRE YEL WIRE

Go to component: -> Shift interlock circuit -> HOT AT ALL TIMES FUSE PANEL C FUSE 14
