Audi A3 8P facelift 2 (2008-2013) fold- in passenger's side outside mirror assembly Wiring diagram
This page shows the only wiring diagram for the component.fold- in passenger's side outside mirror assembly, which is found in the car Audi A3 8P facelift 2 (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fold- in passenger's side outside mirror assembly (1 of 1)
ADJUSTMENT FOLD- MOTORS IN
ADJUSTMENT MOTORS
AUTOMATIC DAY/NIGHT INTERIOR MIRROR (IF EQUIPPED)
AUTOMATIC DAY/NIGHT MIRROR (IF EQUIPPED) MIRROR HEATED SIGNAL MIRROR
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FOLD- IN PASSENGER'S SIDE OUTSIDE MIRROR ASSEMBLY
FUSE 12
FUSE PANEL C
HOT AT ALL TIMES
LIGHT RECOGNITION SENSOR
MIRROR ADJUSTING SWITCH
MIRROR ADJUSTMENT SWITCH
MIRROR SELECTOR SWITCH
MIRROR SWITCH (W/ FOLD AWAY)
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/YEL WIRE
VIO WIRE
VIO/BLK WIRE
YEL WIRE
YEL/BLU WIRE
Go to component: -> Power mirrors circuit -> FOLD- IN PASSENGER'S SIDE OUTSIDE MIRROR ASSEMBLY
