Audi A3 8P facelift 2 (2008-2013) driving dynamics regulation switch valve 1 Wiring diagram

ABS CONTROL MODULE (AT RIGHT REAR OF ENGINE COMPT) ABS HYDRAULIC PUMP ABS HYDRAULIC UNIT ABS WARNING IND ASR/ESP BUTTON BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) BRAKE PAD WEAR IND LAMP ASR/ESP CONTROL LAMP BRAKE PRESSURE SENSOR 1 BRN WIRE COMPUTER DATA LINES SYSTEM DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 1 DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 2 DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 FUSE 22 FUSE 4 FUSE 6 FUSE PANEL GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRY/BLU WIRE HEADLIGHT RANGE CONTROL MODULE (BEHIND RIGHT CENTER OF DASH) HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL B FUSE 25 (INTEGRATED IN ENGINE COMPT E-BOX) HOT W/ MOTRONIC ENGINE CONTROL MODULE (ECM) POWER SUPPLY RELAY HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT ABS INLET VALVE LEFT FRONT ABS OUTLET VALVE LEFT FRONT ABS WHEEL SPEED SENSOR LEFT FRONT BRAKE PAD WEAR SENSOR LEFT FRONT LEVEL CONTROL SYSTEM SENSOR (W/O ELECTRONIC DAMPING) LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE LEFT REAR ABS WHEEL SPEED SENSOR M/T NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT FRONT ABS WHEEL SPEED SENSOR (W/ ELECTRONIC DAMPING) RIGHT REAR ABS INLET VALVE RIGHT REAR ABS OUTLET VALVE RIGHT REAR ABS WHEEL SPEED SENSOR STEERING ANGLE SENSOR (BEHIND STEERING WHEEL) VACUUM SENSOR (IF EQUIPPED) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BELOW LEFT SIDE OF DASH) VIO WIRE VIO/YEL WIRE W/ CORNERING LIGHT W/O CORNERING LIGHT WHT WIRE YEL WIRE
