Audi A3 8P facelift 2 (2008-2013) bridge connector Wiring diagram
This page shows the only wiring diagram for the component.bridge connector, which is found in the car Audi A3 8P facelift 2 (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bridge connector (1 of 1)
AMPLIFIER
AMPLIFIER/ WOOFER
BATTERY
BLK WIRE
BLU WIRE
BRAKE LIGHT/ BRAKE PEDAL SWITCH
BRIDGE CONNECTOR
BRN WIRE
COOLANT FAN CONTROL (FC) MODULE
DATA BUS AUTOMATIC ON BOARD GLOW DIAGNOSTIC TIME INTERFACE CONTROL MODULE
ENGINE CONTROL MODULE (ECM)
FROM FUSE 15 (DIAGRAM 4 OF 4)
FROM FUSE 30 (DIAGRAM 4 OF 4)
FUEL METERING VALVE
FUEL PRESSURE REGULATOR VALVE
FUSE
FUSE 10
FUSE 13
FUSE 14
FUSE 15
FUSE 17
FUSE 18
FUSE 19
FUSE 2
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 27
FUSE 3
FUSE 6
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR
HORN RELAY
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
OXYGEN SENSOR
POWER SUPPLY RELAY (TERMINAL 30, B+)
RED WIRE
STARTER
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
THREE WAY CATALYTIC CONVERTER (TWC)) HEATER
THREE WAY CATALYTIC CONVERTER (TWC)), OXYGEN SENSOR
THROTTLE VALVE CONTROL MODULE
TO FUSE 14 (DIAGRAM 4 OF 4)
TO FUSE 28 (DIAGRAM 2 OF 4)
TO FUSE 3 (DIAGRAM 4 OF 4)
TO FUSE 7 (DIAGRAM 2 OF 4)
TO POWER SUPPLY RELAY 2 (TERMINAL 15) (DIAGRAM 1 OF 4)
TO PREHEATING COOLANT, HIGH HEAT OUTPUT RELAY (DIAGRAM 3 OF 4)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
W/O HILL-HOLD ASSIST W/ HILL-HOLD ASSIST
WASTEGATE BYPASS REGULATOR VALVE
WHT WIRE
WIPER MOTOR CONTROL MODULE
YEL WIRE
Go to component: -> 2.0l turbo diesel, power distribution circuit (4 of 4) -> BRIDGE CONNECTOR
