Headlamps circuit, base for Alfa Romeo Stelvio I (2017-2024)

BATTERY DISTRIBUTION UNIT BLK WIRE BLK/VIO WIRE BODY CONTROL MODULE CIRCUIT BOARD BRN/GRY WIRE CIRCUIT BOARD DK BLU/ORG WIRE DK BLU/WHT WIRE FOG LAMP SW SNS FRT PARK ASSIST FRT PARK ASSIST SW DISABLE/ENABLE FRT PARK ASSIST SW ILL CTRL FUSE 49 FUSE 51 FUSE 72 FUSED B (+) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/GRN WIRE HEADLAMP LEVEL CTRL SIG HEADLAMP SW MUX HEADLAMP SWITCH HOT AT ALL TIMES IGNITION RUN/ IGNITION RUN/START OUTPUT LH DRL LAMP DRV LH HI BEAM DRV LH LOW BEAM DRV LUGGAGE COMPT FLOOR) PANEL LAMPS DIMMER SW MUX PANEL LAMPS DRV RED WIRE RF FOG LAMP CTRL RH DRL LAMP DRV RH HI BEAM DRV RH LOW BEAM DRV START OUTPUT STATUS DISPLAY STOP/START STOP/START SW ILL CTRL STOP/START- STATUS DISPLAY SW DISABLE/ENABLE SW ILL CTRL WHT/DK BLU WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/GRY WIRE

ANTI-LOCK BRAKES MODULE (LEFT REAR OF ENGINE COMPT) BLK WIRE BODY CONTROL MODULE BRN/BLK WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE CAN CH CIRCUIT BOARD COMPUTER DATA LINES SYSTEM DIMMER SWITCH DK BLU/BLK WIRE ELECTRIC PARKING BRAKE SWITCH EPB IND SIG EPB SW POS 1 SIG EPB SW POS 2 SIG EPB SW POS 3 SIG EPB SW POS 4 SIG EPB SW POS 5 SIG EPB SW POS 6 SIG FUSE 36 FUSED B (+) GRN/ORG WIRE GRN/WHT WIRE LEFT FRONT FOG LAMP LEFT LIFTGATE TAIL LAMP ASSEMBLY LEFT MULTI FUNCTION SWITCH LF FOG LAMP CTRL LH HI BEAM DRIVER MUX OFF ORG/ WIRE PANEL LAMPS REAR FOG LAMP FEED RED/GRN WIRE RIGHT FRONT FOG LAMP RIGHT LIFTGATE TAIL LAMP ASSEMBLY VIO/DK BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE YEL WIRE
