Alfa Romeo Stelvio I (2017-2024) trailer tow lh Wiring diagram
This page shows the only wiring diagram for the component.trailer tow lh, which is found in the car Alfa Romeo Stelvio I (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer tow lh (1 of 1)
BATTERY DISTRIBUTION UNIT
BLK WIRE
BODY CONTROL MODULE CIRCUIT BOARD
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/WHT WIRE
DRIVER OUTSIDE REAR- VIEW MIRROR
FUSE 1
FUSE 2
FUSE 72
FUSED B (+)
HOT AT ALL TIMES
LAMP DRV
LH STOP/TURN
LH STOP/TURN LP DRV
LICENSE PLATE
LICENSE PLATE LAMP DRV
LUGGAGE COMPT FLOOR)
PASSENGER OUTSIDE REAR VIEW MIRROR
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RH STOP/TURN
RH STOP/TURN LP DRV
STOP/TURN SIG
TRAILER TOW LH
TRAILER TOW MODULE (LEFT REAR OF VEHICLE)
TRAILER TOW RECEPTACLE 2
TRAILER TOW RH
TRAILER TOW RH STOP/TURN SIG
WHT WIRE
WHT/DK BLU WIRE
YEL/BLK WIRE
Go to component -> Trailer tow circuit -> TRAILER TOW LH
