Alfa Romeo Stelvio I (2017-2024) right rear courtesy lamp Wiring diagram
This page shows the only wiring diagram for the component.right rear courtesy lamp, which is found in the car Alfa Romeo Stelvio I (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear courtesy lamp (1 of 1)
BLK WIRE
DK BLU WIRE
DK BLU/GRY WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
DOME LAMP
DRIVER DOOR MODULE (IN DRIVER FRONT DOOR)
DRIVER DOOR TRIM PDDL LAMP
DRIVER INTERIOR DOOR HANDLE SWITCH
ELECTRONIC OVERHEAD MODULE
GRY/RED WIRE
LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
LEFT REAR COURTESY LAMP
LEFT REAR EXTERIOR DOOR HANDLE LAMP
LIFTGATE RELEASE SWITCH
ORG/ WIRE
ORG/GRY WIRE
PANEL LAMPS DIMM
PANEL LAMPS DIMMER
PANEL LAMPS DRV
PASSENGER DOOR TRIM PDDL LAMP
RIGHT FRONT EXTERIOR DOOR HANDLE SWITCH
RIGHT REAR COURTESY LAMP
RIGHT REAR EXTERIOR DOOR HANDLE LAMP
SW MUX
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> RIGHT REAR COURTESY LAMP
