Alfa Romeo Stelvio I (2017-2024) left front exterior door handle switch Wiring diagrams
This page contains all the electrical diagrams for the component. left front exterior door handle switch, in which he is found in the car Alfa Romeo Stelvio I (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front exterior door handle switch (1 of 2)
BLK WIRE
DK BLU WIRE
DK BLU/GRY WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
DOME LAMP
DRIVER DOOR MODULE (IN DRIVER FRONT DOOR)
DRIVER DOOR TRIM PDDL LAMP
DRIVER INTERIOR DOOR HANDLE SWITCH
ELECTRONIC OVERHEAD MODULE
GRY/RED WIRE
LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
LEFT REAR COURTESY LAMP
LEFT REAR EXTERIOR DOOR HANDLE LAMP
LIFTGATE RELEASE SWITCH
ORG/ WIRE
ORG/GRY WIRE
PANEL LAMPS DIMM
PANEL LAMPS DIMMER
PANEL LAMPS DRV
PASSENGER DOOR TRIM PDDL LAMP
RIGHT FRONT EXTERIOR DOOR HANDLE SWITCH
RIGHT REAR COURTESY LAMP
RIGHT REAR EXTERIOR DOOR HANDLE LAMP
SW MUX
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
Wiring diagram left front exterior door handle switch (2 of 2)
ANT 1 RTN
ANT 1 SIG
ANT 2 RTN
ANT 2 SIG
ANT 5 RTN
ANT 5 SIG
ANT SIG
ANT UHF
BATTERY DISTRIBUTION UNIT
BLK WIRE
BODY CONTROL MODULE
BRK SIG 1
BRN WIRE
CAN C (+)
CAN C (+) PANEL LAMPS DRV
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
CTRL OUT
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
EXTERIOR LIGHTS SYSTEM STARTING/CHARGING SYSTEM
FUSE 36
FUSE 73
FUSED B (+)
FUSED B(+) K LINE COMM
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
IGN RUN/START
IGN RUN/START CTRL OUT
IGN SW SENS
LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
LF PASSIVE ENT HANDLE SW RTN
LF PASSIVE ENT HANDLE SW SENS
LIN BUS
LUGGAGE COMPT FLOOR)
ORG/DK BLU WIRE
PASSIVE ENT ANT 1 RTN
PASSIVE ENT ANT 1 SIG
PASSIVE ENT ANT 2 RTN
PASSIVE ENT ANT 2 SIG
PASSIVE ENT ANT 3 RTN
PASSIVE ENT ANT 3 SIG
PASSIVE ENT ANT 4 RTN
PASSIVE ENT ANT 4 SIG
PASSIVE ENT ANT 5 RTN
PASSIVE ENT ANT 5 SIG
PASSIVE ENTRY 1 ANTENNA
PASSIVE ENTRY 2 ANTENNA
PASSIVE ENTRY 5 ANTENNA
PASSIVE ENTRY ANT 4 RTN
RADIO FREQUENCY HUB MODULE (CENTER OF DASH)
RED/BLK WIRE
RED/GRN WIRE
REMOTE START ANTENNA
RF PASSIVE ENT HANDLE SW RTN
RF PASSIVE ENT HANDLE SW SNS
RIGHT FRONT EXTERIOR DOOR HANDLE SWITCH
RIGHT REAR DOOR
STARTING/CHARGING SYSTEM
VIO/GRN WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Passive entry circuit -> LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
