Alfa Romeo Stelvio I (2017-2024) leak detection pump ctrl Wiring diagram
This page shows the only wiring diagram for the component.leak detection pump ctrl, which is found in the car Alfa Romeo Stelvio I (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leak detection pump ctrl (1 of 1)
5 VOLT SUPPLY
A/C CLUTCH RLY CTRL
A/C PRESSURE SIG
ACTUATOR CTRL
AIR CONDITIONING SYSTEM
AUTO SHUT DOWN RELAY 2
AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY
BLK WIRE
BLK/GRN WIRE
BLOW-BY CONTROL RELAY
BOOST PRESSURE SIG 2
BRN/GRN WIRE
BRN/WHT WIRE
DK BLU/GRN WIRE
DK BLU/RED WIRE
EVAP PURGE CTRL
EVAP/PURGE SOLENOID 2
FRONT POWER DISTRIBUTION CENTER ASSEMBLY
FTIV CTRL
FUSE 11
FUSE 14
FUSE 17
FUSE 22
FUSE 9
FUSED ASD
FUSED ASD RLY OUT
GRN WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LEAK DETECTION MODULE
LEAK DETECTION PRESSURE SENS
LEAK DETECTION PUMP CTRL
ORG/BLK WIRE
ORG/DK BLU WIRE
ORG/RED WIRE
ORG/WHT WIRE
POWERTRAIN CONTROL MODULE 2
PRESSURE SENS +
PUMP CTRL
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY OUT
SENS GND
TURBO SURGE VALVE 2 CTRL
VIO WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/GRN WIRE
Go to component -> Wiring diagram engine performance 2.9l turbo (8 of 12) -> LEAK DETECTION PUMP CTRL
