Alfa Romeo Stelvio I (2017-2024) drv dr secondary ajar sw sens Wiring diagrams

This page contains all the electrical diagrams for the component. drv dr secondary ajar sw sens, in which he is found in the car Alfa Romeo Stelvio I (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram drv dr secondary ajar sw sens (1 of 3)

Wiring diagram drv dr secondary ajar sw sens for Alfa Romeo Stelvio I (2017-2024) (1 of 3)

Get access

AJAR SW SENS BLK WIRE BODY CONTROL MODULE (RIGHT FOOTWELL) CIRCUIT BOARD DK BLU/WHT WIRE DR AJAR SIG DR LK SW RTN DR LK SW RTN DRV DRIVER DOOR LATCH DRV DR DRV DR AJAR SW SENS DRV DR SECONDARY DRV DR SECONDARY AJAR SW SENS LEFT REAR DOOR LATCH LEFT VANITY UGDO LAMP LR DR AJAR SW SENS PASSENGER DOOR LATCH READING LAMPS DRV REAR POWER LIFTGATE SWITCH RIGHT REAR DOOR LATCH RIGHT VANITY LAMP RR DR AJAR SW SENS VIO WIRE VIO/RED WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE

Go to component -> Courtesy lamps circuit (3 of 3) -> DRV DR SECONDARY AJAR SW SENS

Wiring diagram drv dr secondary ajar sw sens (2 of 3)

Wiring diagram drv dr secondary ajar sw sens for Alfa Romeo Stelvio I (2017-2024) (2 of 3)

Get access

AJAR SW SENS BATTERY DISTRIBUTION UNIT BLK WIRE CIRCUIT BOARD DK BLU/RED WIRE DOOR LK DOOR LOCK RELAY DR AJAR SIG DR LK SW DR LK SW RTN DR LK SW RTN DRV DRIVER DOOR LATCH DRIVER DOOR UNLOCK RELAY DRV DOOR UNLK DRV DR AJAR DRV DR AJAR SW SENS DRV DR SECONDARY DRV DR SECONDARY AJAR SW SENS FUEL DOOR MOTOR FUSE 38 FUSE 73 FUSED B (+) HOT AT ALL TIMES LEFT REAR DOOR LATCH LR DR AJAR LUGGAGE COMPT FLOOR) ORG/GRN WIRE ORG/WHT WIRE PASS DR UNLK PASSENGER DOOR LATCH PASSENGER DOOR UNLOCK RELAY RED/BLK WIRE RELAY CTRL RIGHT REAR DOOR LATCH RLY CTRL RR DR AJAR RTN DRV RTN PASS SECONDARY LOCK DRV SW SENS VIO/RED WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE

Go to component -> Forced entry circuit (1 of 2) -> DRV DR SECONDARY AJAR SW SENS
