Alfa Romeo Stelvio I (2017-2024) drive mode position led 3 control Wiring diagram
This page shows the only wiring diagram for the component.drive mode position led 3 control, which is found in the car Alfa Romeo Stelvio I (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive mode position led 3 control (1 of 1)
BATTERY DISTRIBUTION UNIT
BLK WIRE
BODY CONTROL MODULE (RIGHT FOOTWELL)
BRN WIRE
CAN C (+)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DRIVE MODE POSITION LED 3 CONTROL
DRIVE MODE POSITION LED 5 CONTROL
DRIVE MODE SELECT SWITCH
DRIVETRAIN CONTROL MODULE
FRONT POWER DISTRIBUTION CENTER ASSEMBLY
FUSE 15
FUSE 16
FUSE 51
FUSE 73
FUSED B (+)
GRN WIRE
GROUND
GRY/GRN WIRE
HOT AT ALL TIMES
IGNITION RUN 1 RELAY
IGNITION RUN/ START OUTPUT
IGNITION RUN/START OUTPUT
LUGGAGE COMPT FLOOR)
ORG/ WIRE
ORG/DK BLU WIRE
PANEL LAMPS DIMMER SW MUX
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/BLK WIRE
S015 (2.0L TURBO) S013 (2.9L TURBO)
SWITCHED B+
VIO/GRY WIRE
VIO/WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> DRIVE MODE POSITION LED 3 CONTROL
