Alfa Romeo Stelvio I (2017-2024) decklid/ liftgate sig gnd wiring diagram
This page shows the only wiring diagram for the component.decklid/ liftgate sig gnd, which is found in the car Alfa Romeo Stelvio I (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
decklid/ liftgate sig gnd wiring diagram (1 of 1)
B(+)
BATTERY DISTRIBUTION UNIT
BLK WIRE
BRN WIRE
CAN (-) CAN (+)
CAN C (+)
CIRCUIT BOARD
CLUSTER
COMPUTER DATA LINES SYSTEM
DECKLID RELEASE SWITCH 2
DECKLID/ DECKLID/ LIFTGATE LIFTGATE RELEASE GND DRV SIG (-) (+)
DECKLID/ LIFTGATE RELEASE DRV
DECKLID/ LIFTGATE SIG GND
DRV DOOR LK SW RTN
FUSE 38
FUSE 72
FUSED B (+)
GRN WIRE
HOT AT ALL TIMES
LIFTGATE DOOR LATCH
LIFTGATE UNLK RLY
LIFTGATE UNLOCK RELAY
LUGGAGE COMPT FLOOR)
ORG/ WIRE
RED WIRE
VIO WIRE
WHT WIRE
Go to component -> Deck lid release circuit -> DECKLID/ LIFTGATE SIG GND
