Alfa Romeo Stelvio I (2017-2024) coolant pmp rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.coolant pmp rly ctrl, which is found in the car Alfa Romeo Stelvio I (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant pmp rly ctrl (1 of 1)
AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BOOST PRESSURE SENSOR 1
BOOST PRESSURE SIG
BRN/GRN WIRE
BRN/VIO WIRE
COOLANT PMP RLY CTRL
COOLING FANS SYSTEM
CURRENT TRIM
DK BLU/GRN WIRE
DK BLU/RED WIRE
ECT SIG
ENGINE COOLANT TEMPERATURE SENSOR 1
EVAP PURGE CTRL
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSED ASD
FUSED ASD RELAY OUT
GRN/WHT WIRE
GRY/BLK WIRE
GRY/GRN WIRE
HOOD AJAR SW SIG
HOOD AJAR SWITCH 2
ORG/BLK WIRE
ORG/DK BLU WIRE
ORG/WHT WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
RAD FAN CTRL
RED WIRE
RED/BLK WIRE
RED/DK BLU WIRE
RED/YEL WIRE
RELAY OUT
SECONDARY AIR PUMP RELAY
SENS GND
TURBO SURGE VALVE 1 CTRL
TURBOCHARGER SURGE VALVE
VALVE 1 CTRL
WHT/BLK WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Wiring diagram engine performance 2.9l turbo (1 of 12) -> COOLANT PMP RLY CTRL
