Alfa Romeo Stelvio I (2017-2024) cac pump relay ctrl coolant pump relay ctrl Wiring diagrams

2.0L TURBO 2.9L TURBO 2.9L TURBO, 2.0L TURBO HEAVY DUTY 2.0L TURBO LIGHT DUTY 2.0L TURBO 2.9L TURBO A/C CLUTCH RLY CTRL A/C PRESS SIG AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY BLK WIRE BRN/BLU WIRE BRN/GRY WIRE CAC AIR TEMP SIG CAC AIR TEMPERATURE SENSOR CAC PUMP RELAY CTRL COOLANT PUMP RELAY CTRL CHARGE AIR COOLANT SENSOR CHARGE AIR COOLANT TEMP SIG CHARGE AIR COOLER COOLANT PUMP COMPUTER DATA LINES SYSTEM COOLANT BYPASS VALVE COOLANT BYPASS VLV CTRL DK BLU/RED WIRE ECT SIG ECT SIG 2 ELEC COOLANT PUMP O/P ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 FRONT POWER DISTRIBUTION CENTER ASSEMBLY FSD B(+) FUSE 100 FUSE 23 FUSE 7 5 FUSE 8 FUSE 84 FUSED ASD RLY O/P FUSED B (+) FUSED ASD RLY O/P GRN WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/DK BLU WIRE GRY/GRN WIRE HI TEMP CTRL VLV DRV HI TEMP CTRL VLV SENS SIG HOT AT ALL TIMES HOT W/ AUTO SHUT DOWN RELAY ENERGIZED LIN BUS ORG/BLK WIRE ORG/GRN WIRE ORG/WHT WIRE POSITIVE REMOTE JUMP POST POWERTRAIN CONTROL MODULE RAD FAN CTRL RADIATOR FAN (FRONT OF ENGINE COMPT) RED WIRE RED/YEL WIRE S020 (2.0L TURBO) S017 (2.9L TURBO) S104 (2.0L TURBO) S003A (2.9L TURBO) S797 (2.0L TURBO) S794 (2.9L TURBO) SENS GND SK917 (2.0L TURBO) VIO/ORG WIRE VIO/WHT WIRE WATER PUMP RELAY WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

2.0L TURBO 2.9L TURBO 2.9L TURBO, 2.0L TURBO HEAVY DUTY 2.0L TURBO LIGHT DUTY 2.0L TURBO 2.9L TURBO A/C PRESS SIG AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY BLK WIRE BRN/BLU WIRE BRN/GRY WIRE CAC AIR TEMP SIG CAC AIR TEMPERATURE SENSOR CAC PUMP RELAY CTRL COOLANT PUMP RELAY CTRL CHARGE AIR COOLANT SENSOR CHARGE AIR COOLANT TEMP SIG CHARGE AIR COOLER COOLANT PUMP COMPUTER DATA LINES SYSTEM COOLANT BYPASS VALVE COOLANT BYPASS VLV CTRL DK BLU/RED WIRE ECT SIG ECT SIG 2 ELEC COOLANT PUMP O/P ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 FRONT POWER DISTRIBUTION CENTER ASSEMBLY FSD B(+) FUSE 100 FUSE 23 FUSE 7 5 FUSE 8 FUSE 84 FUSED ASD RLY O/P FUSED B (+) FUSED ASD RLY O/P GRN WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/DK BLU WIRE GRY/GRN WIRE HI TEMP CTRL VLV DRV HI TEMP CTRL VLV SENS SIG HOT AT ALL TIMES HOT W/ AUTO SHUT DOWN RELAY ENERGIZED LIN BUS ORG/BLK WIRE ORG/GRN WIRE POSITIVE REMOTE JUMP POST POWERTRAIN CONTROL MODULE RAD FAN CTRL RADIATOR FAN (FRONT OF ENGINE COMPT) RED WIRE RED/YEL WIRE S020 (2.0L TURBO) S017 (2.9L TURBO) S104 (2.0L TURBO) S003A (2.9L TURBO) S797 (2.0L TURBO) S794 (2.9L TURBO) SENS GND SK917 (2.0L TURBO) VIO/ORG WIRE VIO/WHT WIRE WATER PUMP RELAY WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
