Wiring diagram blk (61 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (61 of 123)

Get access

BATTERY DISTRIBUTION UNIT BLK WIRE BODY CONTROL MODULE (RIGHT FOOTWELL) BRN WIRE CAN C (+) CIRCUIT BOARD COMPUTER DATA LINES SYSTEM DK BLU WIRE DRIVE MODE POSITION LED 3 CONTROL DRIVE MODE POSITION LED 5 CONTROL DRIVE MODE SELECT SWITCH DRIVETRAIN CONTROL MODULE FRONT POWER DISTRIBUTION CENTER ASSEMBLY FUSE 15 FUSE 16 FUSE 51 FUSE 73 FUSED B (+) GRN WIRE GROUND GRY/GRN WIRE HOT AT ALL TIMES IGNITION RUN 1 RELAY IGNITION RUN/ START OUTPUT IGNITION RUN/START OUTPUT LUGGAGE COMPT FLOOR) ORG/ WIRE ORG/DK BLU WIRE PANEL LAMPS DIMMER SW MUX REAR POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RED/BLK WIRE S015 (2.0L TURBO) S013 (2.9L TURBO) SWITCHED B+ VIO/GRY WIRE VIO/WHT WIRE YEL WIRE

Go to component -> Awd circuit -> BLK WIRE

Wiring diagram blk (62 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (62 of 123)

Get access

BATTERY DISTRIBUTION UNIT BLK WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CAN BUS SPLICE BLOCK 2 CAN C (+) CAN CH CAN IHS (-) CIRCUIT BOARD CLUSTER COMPASS MODULE DATA LINK CONNECTOR 1 (LOWER LEFT SIDE OF DASH) DK BLU WIRE DK BLU/GRN WIRE FSD IGN FUSE 36 FUSE 49 FUSE 73 FUSED B (+) GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/WHT WIRE HANDSFREE LIFTGATE MODULE HOT AT ALL TIMES LIN BUS LIN BUS 1 LIN BUS 2 LIN BUS 3 LIN BUS DR LIN BUS LT LUGGAGE COMPT FLOOR) OCCUPANT RESTRAINT CONTROLLER MODULE OUTPUT RADIO FREQUENCY HUB MODULE RED/BLK WIRE RED/GRN WIRE RUN/START SIG RT SW MOD RTN WHT WIRE WHT/DK BLU WIRE

Go to component -> Computer data lines circuit (1 of 6) -> BLK WIRE

Wiring diagram blk (63 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (63 of 123)

Get access

2.0L TURBO 2.9L TURBO BLK WIRE BRN WIRE BRN/WHT WIRE CAN C (+) CAN CH CAN IHS (-) DIAGNOSTIC CAN C (+) DIAGNOSTIC CAN CH (-) DIAGNOSTIC CAN IHS (-) DK BLU WIRE DK BLU/GRN WIRE DRIVER INTERIOR DOOR HANDLE SWITCH FRONT WIPER MOTOR FUSED B (+) GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/GRN WIRE LIN BUS 2 LIN BUS DR OUTPUT PARK ASSIST MODULE RADIO RED/GRN WIRE RUN/START S895 (2.0L TURBO) S898 (2.9L TURBO) S897 (2.0L TURBO) SECURITY GATEWAY MODULE SW MOD RTN WHT WIRE WHT/DK BLU WIRE

Go to component -> Computer data lines circuit (2 of 6) -> BLK WIRE

Wiring diagram blk (64 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (64 of 123)

Get access

2.0L TURBO, 2.9L TURBO ANTI-LOCK BRAKES MODULE BATTERY DISTRIBUTION UNIT BLK WIRE BLK/VIO WIRE BODY CONTROL MODULE CIRCUIT BOARD BRK SIG 1 BRN WIRE CAN C (+) CIRCUIT BOARD CLUSTER COMPUTER DATA LINES SYSTEM DK BLU/ORG WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE FRT SIDE MARKER FUSE 49 FUSE 72 FUSED B (+) GRN WIRE GRN/WHT WIRE HEADLAMP SW MUX HEADLAMP SWITCH HOT AT ALL TIMES IGNITION RUN/ IGNITION RUN/ START OUTPUT LAMP CTRL LEFT LIFTGATE TAIL LAMP ASSEMBLY LEFT MULTI FUNCTION SWITCH LEFT TAIL LAMP ASSEMBLY LF LIGHTING FAULT SNS LF TURN SIG LAMP DRV LH LED SIDE MARKER CTRL LH STOP LAMP DRV LH TAIL LAMP FAULT SNS LH TAIL LAMP FAULT SNS 2 LIFTGATE SW SIG LR TURN LAMP DRV LUGGAGE COMPT FLOOR) PARK LAMP LED POWERTRAIN CONTROL MODULE POWERTRAIN CONTROL MODULE 2 PREMIUM BASE RADIO FREQUENCY HUB MODULE RED WIRE START OUTPUT TURN SIGNALS WHT/BLK WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE

Go to component -> Exterior lamps circuit (1 of 2) -> BLK WIRE

Wiring diagram blk (65 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (65 of 123)

Get access

AUXILIARY BANK SWITCH BLK WIRE BODY CONTROL MODULE (RIGHT FOOTWELL) BRK LAMP SW OUTPUT BRN WIRE CAN IHS (-) CENTER HIGH MOUNTED STOP LAMP CIRCUIT BOARD CIRCUIT BOARD RIGHT FRONT LAMP ASSEMBLY COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/BLK WIRE DK BLU/YEL WIRE FUSE 53 FUSED B (+) FUSED B (+) HAZARD SW SNS GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD IND CTRL HAZARD SW SNS LEFT LICENSE LAMP LICENSE PLATE LAMP DRV PANEL LMPS PREMIUM BASE RED/GRN WIRE RF LIGHTING FAULT SNS RF TURN SIG LAMP DRV RH STOP LAMP DRV RH TAIL LAMP FAULT SNS RH TAIL LAMP FAULT SNS 2 RIGHT LICENSE LAMP RIGHT LIFTGATE TAIL LAMP ASSEMBLY RIGHT TAIL LAMP ASSEMBLY RR SIDE MARKER CTRL RR TURN LAMP DRV WHT WIRE WHT/BLK WIRE WHT/GRY WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

Go to component -> Exterior lamps circuit (2 of 2) -> BLK WIRE

Wiring diagram blk (66 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (66 of 123)

Get access

BLK WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BRN/BLK WIRE CAN IHS (-) COMFORT SEAT STEERING WHEEL MODULE COMPUTER DATA LINES SYSTEM DK BLU WIRE DRIVER SEAT BACK HEATER DRIVER SEAT CUSHION HEATER DRIVER SEAT SWITCH DRV FRT HTD SEAT TEMP SNS DRV FRT SEAT HTR CTRL FUSE 20 GND PNK/ WIRE GRN/RED WIRE GRY/RED WIRE HOT AT ALL TIMES HTD SEAT SENS RTN MEMORY SYSTEMS ORG/ WIRE PASS FRT HTD SEAT TEMP SNS PASS FRT SEAT HTR CTRL PASSENGER SEAT BACK HEATER PASSENGER SEAT CUSHION HEATER PNK FUSED B (+) WIRE REAR POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RED/WHT WIRE SEAT SW/ SEAT SW/ SENS GND SENS GND VIO/YEL WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

Go to component -> Front heated seats circuit -> BLK WIRE

Wiring diagram blk (67 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (67 of 123)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE CAN IHS (-) COMFORT SEAT STEERING WHEEL MODULE COMPUTER DATA LINES SYSTEM FUSE 20 FUSED B (+) GRY WIRE GRY/GRN WIRE HOT AT ALL TIMES HTD STRNG HTD STRNG WHEEL FEED HTD STRNG WHEEL RTN LIN BUS ORG/ WIRE PNK WIRE PNK/DK BLU WIRE REAR POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RED/WHT WIRE RIGHT STEERING WHEEL SWITCH STEERING COLUMN CONTROL MODULE STEERING WHEEL HEATER WHEEL SIG WHT/DK BLU WIRE YEL WIRE

Go to component -> Heated steering wheel circuit -> BLK WIRE

Wiring diagram blk (68 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (68 of 123)

Get access

BATTERY DISTRIBUTION UNIT BLK WIRE BLK/GRN WIRE BODY CONTROL MODULE BRN/GRN WIRE BRN/GRY WIRE CIRCUIT BOARD DIM SW MUX DOOR MODULE FEED DOOR MODULE FEED TO DOOR SW DRIVER DOOR MODULE (IN DRIVER FRONT DOOR) DRIVER WINDOW MOTOR DRV WIND DRV DOWN DRV WIND DRV UP FUSE 33 FUSE 34 FUSE 47 FUSE 48 FUSE 73 FUSED B (+) GRN/YEL WIRE GRY/BLK WIRE GRY/GRN WIRE HOT AT ALL TIMES LEFT REAR POWER WINDOW SWITCH LEFT REAR WINDOW MOTOR LIN BUS 3 LR WIND LUGGAGE COMPT FLOOR) MASTER WIND MASTER WIND SW LR (UP) MASTER WIND SW RR (UP) PANEL LAMPS DIMMER SW MUX PANEL LPS PASS WIND SW MUX PASSENGER DOOR MODULE (IN PASSENGER FRONT DOOR) PASSENGER WINDOW MOTOR REAR WINDOWS LOCK/ REAR WINDOWS LOCK/ UNLOCK LED DRV RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT REAR POWER WINDOW SWITCH RIGHT REAR WINDOW MOTOR RR WIND SW MUX SW LR (UP) SW MUX SW OUT SW RR (UP) TO DOOR SW UNLOCK LED DRV WIND LK OUT WIND LK OUT SW OUT YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit -> BLK WIRE

Wiring diagram blk (69 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (69 of 123)

Get access

BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/GRY WIRE BRN/WHT WIRE CAN IHS (-) CAN IHS (-) HEATED SEAT SENSOR RETURN COMPUTER DATA LINES SYSTEM FUSE 18 FUSE 21 FUSE 81 FUSED B (+) FUSED B (+) GND GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEATED SEAT SENSOR RETURN HEATED SEATS MODULE HOT AT ALL TIMES LEFT REAR HEATED SEAT TEMP SENSE LEFT REAR SEAT BACK HEATER LEFT REAR SEAT CUSHION HEATER LEFT REAR SEAT HEATER CONTROL LIN BUS PNK WIRE PNK/DK BLU WIRE REAR HEATED SEAT/ USB CHARGING PORT SWITCH REAR POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT REAR HEATED SEAT TEMP SENSE RIGHT REAR SEAT BACK HEATER RIGHT REAR SEAT CUSHION HEATER RIGHT REAR SEAT HEATER CONTROL WHT/DK BLU WIRE WHT/RED WIRE WHT/VIO WIRE YEL/DK BLU WIRE

Go to component -> Rear heated seats circuit -> BLK WIRE

Wiring diagram blk (70 of 123)

Wiring diagram blk for Alfa Romeo Stelvio I (2017-2024) (70 of 123)

Get access

BATTERY DISTRIBUTION UNIT BLK WIRE BODY CONTROL MODULE CIRCUIT BOARD CAN IHS (-) COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/BLK WIRE DK BLU/WHT WIRE DRIVER OUTSIDE REAR- VIEW MIRROR FUSE 1 FUSE 2 FUSE 72 FUSED B (+) HOT AT ALL TIMES LAMP DRV LH STOP/TURN LH STOP/TURN LP DRV LICENSE PLATE LICENSE PLATE LAMP DRV LUGGAGE COMPT FLOOR) PASSENGER OUTSIDE REAR VIEW MIRROR REAR POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RED/GRN WIRE RED/YEL WIRE RH STOP/TURN RH STOP/TURN LP DRV STOP/TURN SIG TRAILER TOW LH TRAILER TOW MODULE (LEFT REAR OF VEHICLE) TRAILER TOW RECEPTACLE 2 TRAILER TOW RH TRAILER TOW RH STOP/TURN SIG WHT WIRE WHT/DK BLU WIRE YEL/BLK WIRE

Go to component -> Trailer tow circuit -> BLK WIRE
