Car Wiring Diagrams for Electric parking brake circuit for Alfa Romeo Giulia 952 (2016-2024)

2.0L TURBO 2.9L TURBO ANTI-LOCK BRAKES MODULE BATTERY DISTRIBUTION UNIT BLK WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CAN C (+) CIRCUIT BOARD COMPUTER DATA LINES SYSTEM ELECTRIC PARKING BRAKE SWITCH EPB INDICATOR SIG EPB SW POS 1 SIG EPB SW POS 2 SIG EPB SW POS 3 SIG EPB SW POS 4 SIG EPB SW POS 5 SIG EPB SW POS 6 SIG FRONT POWER DISTRIBUTION CENTER ASSEMBLY FUSE 36 FUSE 4 FUSE 60 FUSE 72 FUSE 82 FUSED B (+) GRN WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES LEFT REAR ELECTRIC PARKING BRAKE ACTUATOR LH EPB ACTR A CTRL LH EPB ACTR B CTRL OFF REAR POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RED/BLK WIRE RED/DK BLU WIRE RED/GRN WIRE RH EPB ACTR A CTRL RH EPB ACTR B CTRL RIGHT REAR ELECTRIC PARKING BRAKE ACTUATOR VIO/DK BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
