Alfa Romeo Giulia 952 (2016-2024) trailer tow connector 2 Wiring diagram
This page shows the only wiring diagram for the component.trailer tow connector 2, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer tow connector 2 (1 of 1)
2.0L TURBO
BACKUP LP FEED
BATTERY DISTRIBUTION UNIT
BLK WIRE
BRAKE LP SW OUTPUT
BRN/YEL WIRE
CAN IHS (-)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/GRY WIRE
DK BLU/WHT WIRE
DRIVER OUTSIDE REAR- VIEW MIRROR
FUSE 1
FUSE 2
FUSE 3
FUSE 4
FUSE 51
FUSE 73
FUSED B (+)
GRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGNITION RUN/
IGNITION RUN/ START OUTPUT
LH STOP LP DRV
PASSENGER OUTSIDE REAR VIEW MIRROR
REAR FOG LP FEED
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RH STOP LP DRV
START OUTPUT
STOP/TURN SIG
TRAILER TOW CONNECTOR 1
TRAILER TOW CONNECTOR 2
TRAILER TOW LH
TRAILER TOW LH STOP/TURN SIG
TRAILER TOW MODULE (LEFT REAR OF VEHICLE)
TRAILER TOW RELAY
TRAILER TOW RH
TRAILER TOW RH STOP/TURN SIG
WHT WIRE
YEL WIRE
YEL/BLK WIRE
