Alfa Romeo Giulia 952 (2016-2024) sw ill ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. sw ill ctrl, in which he is found in the car Alfa Romeo Giulia 952 (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sw ill ctrl (1 of 2)
2.0L TURBO
BATTERY DISTRIBUTION UNIT
BLK/GRN WIRE
BLK/VIO WIRE
BRN/GRY WIRE
CIRCUIT BOARD
DK BLU WIRE
DK BLU/WHT WIRE
FRT FOG LP RLY CTRL
FRT PARK ASSIST SW DISABLE/ENABLE
FRT PARK ASSIST SW ILL CTRL
FUSE 49
FUSE 51
FUSE 73
FUSED B (+)
FUSED IGNITION
FUSED IGNITION SW OUTPUT (RUN)
GRN WIRE
GRN/ORG WIRE
GRY/BLK WIRE
GRY/DK BLU WIRE
GRY/GRN WIRE
HEADLAMP LEVELING
HEADLAMP LEVELING SENS FRT SIG
HEADLAMP SW SIG
HEADLAMP SWITCH
HOT AT ALL TIMES
IGNITION RUN/
IGNITION RUN/ START OUTPUT
LH DRL LP DRV
LH HI BEAM DRV
LH LOW BEAM DRV
NAVIGATION SYSTEM
PANEL LMPS
PANEL LPS DRV
RED WIRE
RED/BLK WIRE
RF FOG LP CTRL
RH DRL LP DRV
RH HI BEAM DRV
RH LOW BEAM DRV
RIGHT FRONT FOG LAMP
SENS FRT SIG
START OUTPUT
STATUS DISPLAY
STOP/START
STOP/START SW ILL CTRL
STOP/START- STATUS DISPLAY
SW ILL CTRL
SW OUTPUT (RUN)
VIO/GRY WIRE
WHT/DK BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Headlamps circuit, base (1 of 2) -> SW ILL CTRL
Wiring diagram sw ill ctrl (2 of 2)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BRN/GRY WIRE
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
FAULT FEED
FRT FOG LP RLY CTRL
FRT PARK ASSIST SW DISABLE/ENABLE
FRT PARK ASSIST SW ILL CTRL
FUSE 49
FUSE 51
FUSED IGNITION
FUSED IGNITION SW OUTPUT (RUN)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY/BLK WIRE
GRY/DK BLU WIRE
GRY/GRN WIRE
HEADLAMP SW SIG
HEADLAMP SWITCH
IGNITION RUN/
IGNITION RUN/ START OUTPUT
LIN BUS
NAVIGATION SYSTEM
PANEL LMPS
PANEL LPS DRV
RF FOG LP CTRL
RF LIGHTING
RF LIGHTING FAULT SNS
RH DRL LP DRV
RH HI BEAM DRV
RH LOW BEAM DRV
RIGHT FRONT FOG LAMP
START OUTPUT
STATUS DISPLAY
STOP/START
STOP/START SW ILL CTRL
STOP/START- STATUS DISPLAY
SW ILL CTRL
SW OUTPUT (RUN)
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlamps circuit, premium (2 of 2) -> SW ILL CTRL
