Alfa Romeo Giulia 952 (2016-2024) steering wheel sensor module Wiring diagram
This page shows the only wiring diagram for the component.steering wheel sensor module, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel sensor module (1 of 1)
A/C HEATER CONTROL
BLK/PNK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAN BUS SPLICE BLOCK 3 (UNDER DRIVER'S SEAT)
CAN BUS SPLICE BLOCK 4
CAN IHS (-)
COMFORT SEAT STEERING WHEEL MODULE
DK BLU WIRE
DK BLU/GRN WIRE
DK BLU/WHT WIRE
ENGINE SOUND ENHANCEMENT MODULE
GRY/BLK WIRE
GRY/GRN WIRE
HEATED SEATS MODULE
HUMIDITY SENSOR
HVAC MODULE
IHS (+)
LEFT REAR BLIND-SPOT SENSOR
LIN BUS
PNK/DK BLU WIRE
RADIO, AMPLIFIER
REAR HEATED SEAT/USB CHARGING PORT SWITCH
RIGHT REAR BLIND-SPOT SENSOR
RIGHT STEERING WHEEL SWITCH
SPEED CONTROL SWITCH
STEERING WHEEL SENSOR MODULE
TRAILER TOW MODULE
VIO WIRE
WHT WIRE
WHT/GRY WIRE
WHT/PNK WIRE
YEL/GRY WIRE
Go to component -> Computer data lines circuit (6 of 6) -> STEERING WHEEL SENSOR MODULE
