Alfa Romeo Giulia 952 (2016-2024) run/ start relay control gnd Wiring diagram
This page shows the only wiring diagram for the component.run/ start relay control gnd, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram run/ start relay control gnd (1 of 1)
ADAPTIVE CRUISE CONTROL MODULE
B(+)
BLK WIRE
BLK/VIO WIRE
BLOWER MOTOR RELAY
CIGAR LIGHTER
CIRCUIT BOARD
CLUSTER
COMPUTER DATA LINES SYSTEM
CONSOLE POWER OUTLET
DIM SW
DK BLU WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DOOR LOCK RELAY
DRIVER DOOR UNLOCK RELAY
FORWARD FACING CAMERA
FROM FUSE 21 (DIAGRAM 1 OF 7)
FROM REAR POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 1 OF 7)
FRONT CHARGING USB PORT
FRONT POWER DISTRIBUTION CENTER ASSEMBLY
FRONT WASHER PUMP RELAY
FUSE 11
FUSE 17
FUSE 22
FUSE 31
FUSE 37
FUSE 38
FUSE 43
FUSE 94
FUSED B (+)
FUSED IGN SW
GROUND
GRY/GRN WIRE
GRY/RED WIRE
HEADLAMP WASHER RELAY
IGN
IGN (RUN)
IGNITION RUN 2 RELAY
LIFTGATE UNLOCK RELAY
LIN BUS 2
LPS DIM
MEDIA PORT
MULTIMEDIA CONTROL ENTERTAINMENT MODULE
O/P (RUN-ACC)
ORG/WHT WIRE
OUTPUT
PANEL LPS
PANEL)
PASSENGER DOOR UNLOCK RELAY
POWER OUTLET RELAY
POWER SEAT RELAY
PWR OUTLET
REAR CHARGING USB PORT
REAR HEATED SEAT/USB CHARGING PORT SWITCH
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RLY O/P 1
RUN/ START RELAY CONTROL GND
STARTER SOLENOID 2 RELAY
UCI USB RADIO DATA (+)
WHT/RED WIRE
WIRELESS CHARGING MODULE
YEL WIRE
Go to component -> Power distribution circuit (2 of 7) -> RUN/ START RELAY CONTROL GND
