Alfa Romeo Giulia 952 (2016-2024) rh side repeater lamp Wiring diagram
This page shows the only wiring diagram for the component.rh side repeater lamp, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rh side repeater lamp (1 of 1)
2.0L TURBO
ANTI-LOCK BRAKES MODULE
BATTERY DISTRIBUTION UNIT
BLK WIRE
BRAKE SIG 1
BRN/BLK WIRE
BRN/GRY WIRE
BRN/YEL WIRE
CIRCUIT BOARD
DK BLU/WHT WIRE
FUSE 51
FUSE 73
FUSED B (+)
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IGNITION RUN/
IGNITION RUN/ START OUTPUT
LAMP DRV
LEFT LICENSE LAMP
LEFT TAIL LAMP ASSEMBLY
LF TURN LP DRV
LH SIDE
LH SIDE MARKER CTRL
LH SIDE REPEATER LAMP
LH STOP LP DRV
LICENSE PLATE
LICENSE PLATE LAMP DRV
LR STOP/TURN
LR STOP/TURN SIG FEED
MARKER CTRL
ORG/ WIRE
POWERTRAIN CONTROL MODULE (2.0L TURBO)
POWERTRAIN CONTROL MODULE 2 (2.9L TURBO)
PREMIUM
RADIO FREQUENCY HUB MODULE
RED WIRE
RED/BLK WIRE
REPEATER LAMP
RF TURN LP DRV
RH SIDE
RH SIDE REPEATER LAMP
RH STOP LP DRV
RIGHT LICENSE LAMP
RIGHT TAIL LAMP ASSEMBLY
RR SIDE
RR SIDE MARKER LP CTRL
RR STOP/TURN
RR STOP/TURN SIG FEED
RR TURN LP DRV
SIG FEED
START OUTPUT
WHT/BLK WIRE
WHT/DK BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> RH SIDE REPEATER LAMP
