Alfa Romeo Giulia 952 (2016-2024) rh blind spot ind drv Wiring diagram
This page shows the only wiring diagram for the component.rh blind spot ind drv, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rh blind spot ind drv (1 of 1)
2.0L TURBO
BATTERY DISTRIBUTION UNIT
BLK WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
CAN IHS (-)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DRIVER OUTSIDE REAR- VIEW MIRROR
FSD IGN RUN/ START O/P (RUN)
FSD IGN SWITCH O/P (RUN)
FUSE 49
FUSE 73
FUSED B (+)
FUSED IGN RUN
GRN WIRE
GRN/GRY WIRE
HOT AT ALL TIMES
LEFT REAR BLIND-SPOT SENSOR
LH BLIND SPOT IND DRV
PASSENGER OUTSIDE REAR VIEW MIRROR
RED/BLK WIRE
RH BLIND SPOT IND DRV
RIGHT REAR BLIND-SPOT SENSOR
WHT WIRE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> RH BLIND SPOT IND DRV
