Alfa Romeo Giulia 952 (2016-2024) left front wheel acceleration sensor Wiring diagram
This page shows the only wiring diagram for the component.left front wheel acceleration sensor, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front wheel acceleration sensor (1 of 1)
BATTERY DISTRIBUTION UNIT
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
CAN C (+)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK BLU/YEL WIRE
FSD ASD
FSD B(+)
FUSE 42
FUSE 73
GRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT FRONT BODY ACCELERATION SENSOR
LEFT FRONT WHEEL ACCELERATION SENSOR
LF BODY ACCEL
LF WHEEL ACCEL
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RF BODY ACCEL
RF WHEEL ACCEL
RIGHT FRONT BODY ACCELERATION SENSOR
RIGHT FRONT WHEEL ACCELERATION SENSOR
RLY OUT
RTN SIGNAL
SENS RTN
SENS SIG
SENS SIGNAL
WHT/BLK WIRE
WHT/GRN WIRE
WHT/YEL WIRE
Go to component -> Active damping circuit (2 of 2) -> LEFT FRONT WHEEL ACCELERATION SENSOR
