Alfa Romeo Giulia 952 (2016-2024) ign sw sns Wiring diagram
This page shows the only wiring diagram for the component.ign sw sns, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign sw sns (1 of 1)
2.0L TURBO
2.0L TURBO, 2.9L TURBO
2.9L TURBO
AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY
BATTERY
BATTERY DISTRIBUTION UNIT
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU/RED WIRE
FRONT POWER DISTRIBUTION CENTER ASSEMBLY
FSD B(+)
FUSE 1
FUSE 71
FUSE 73
FUSE 84
FUSE 90
GENERATOR
GRN WIRE
GRN/GRY WIRE
GROUND
HOT W/ MAIN RELAY ENERGIZED
IGN SW SNS
INTELLIGENT BATTERY SENSOR
KEYLESS IGNITION NODE MODULE
LIN BUS 1
ON BATTERY)
ORG/ WIRE
PANEL LPS
POSITIVE REMOTE JUMP POST
PYROTECHNIC FUSE
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
S001C (2.9L TURBO)
S088 (2.9L TURBO)
SEC K LIN
START STOP
STARTER
WHT/RED WIRE
YEL WIRE
Go to component -> Starting circuit (1 of 2) -> IGN SW SNS
