Alfa Romeo Giulia 952 (2016-2024) forward facing camera windshield defroster driver Wiring diagram
This page shows the only wiring diagram for the component.forward facing camera windshield defroster driver, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram forward facing camera windshield defroster driver (1 of 1)
2.0L TURBO
BATTERY DISTRIBUTION UNIT
BLK WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
BRN/BLK WIRE
BRN/DK BLU WIRE
BRN/WHT WIRE
CAN IHS (-)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
CONTROL
DE-ICER SUPPLY
DEFOGGER RELAY
DK BLU WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DRIVER OUTSIDE REAR- VIEW MIRROR
ELECTRIC HEATED BACKLITE
FORWARD FACING CAMERA (TOP CENTER OF WINDSHIELD)
FORWARD FACING CAMERA WINDSHIELD DEFROSTER DRIVER
FORWARD FACING CAMERA WINDSHIELD DEFROSTER GROUND
FORWARD FACING WINDSHIELD CAMERA HEATER
FUSE 37
FUSE 73
FUSE 74
FUSE 88
FUSE 89
FUSE 94
FUSED B (+)
GROUND
HEADLAMP LOW BEAM GND RT
HOT AT ALL TIMES
HVAC MODULE (TOP OF HVAC BLOWER UNIT)
IGNITION RUN 2 RELAY
IGNITION RUN/
IGNITION RUN/START OUTPUT
PASSENGER OUTSIDE REAR VIEW MIRROR
REAR DEFROST RELAY
REAR POWER DISTRIBUTION CENTER ASSEMBLY
REAR WINDOW
REAR WINDOW DEFOGGER CONTROL OUTPUT
RED WIRE
RED/BLK WIRE
START OUTPUT
TAN/BLK WIRE
VIO WIRE
VIO/BLK WIRE
WASHER NOZZLE HEATER 1
WASHER NOZZLE HEATER 2
WHT WIRE
WHT/PNK WIRE
YEL/GRY WIRE
Go to component -> Defoggers circuit -> FORWARD FACING CAMERA WINDSHIELD DEFROSTER DRIVER
