Alfa Romeo Giulia 952 (2016-2024) drive train control module Wiring diagram
This page shows the only wiring diagram for the component.drive train control module, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive train control module (1 of 1)
1/2 OXYGEN SENSOR
2.0L TURBO
2.9L TURBO
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR SOLENOID
A/C HEATER CONTROL
ACTIVE AERODYNAMIC SYSTEM MODULE 1
ACTIVE AERODYNAMIC SYSTEM MODULE 2
ADAPTIVE CRUISE CONTROL MODULE
AIR QUALITY SENSOR
AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY
AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY 1
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
CHARGE AIR COOLER COOLANT PUMP
COOLANT BYPASS VALVE
DRIVE TRAIN CONTROL MODULE
ELECTRIC BRAKE BOOSTER MODULE
ELECTRIC PARKING BRAKE MODULE
ENGINE OIL VAPOR HEATER
EVAP PURGE SOLENOID
FRONT CUPHOLDER LAMP
FRONT WIPER MOTOR
HEADLAMP WASHER MOTOR
HIGH TEMPERATURE COOLANT CONTROL VALVE
HOOD AJAR SWITCH
HOOD AJAR SWITCH 2
HORN 1
HVAC MODULE
IGNITION CONTROL MODULE
IN-CAR TEMPERATURE SENSOR
INTAKE OXYGEN SENSOR
LEFT FRONT FOG LAMP
MASS AIR FLOW SENSOR
OIL PUMP SOLENOID
OXYGEN SENSOR 1/1
POWERTRAIN CONTROL MODULE
POWERTRAIN CONTROL MODULE 2
RIGHT FRONT FOG LAMP
STARTER RELAY
STARTER SOLENOID RELAY 1
TAN/BLK WIRE
WASHER NOZZLE HEATER 1
WASHER NOZZLE HEATER 2
WINDSHIELD WASHER PUMP
Go to component -> Ground distribution circuit (1 of 5) -> DRIVE TRAIN CONTROL MODULE
