Alfa Romeo Giulia 952 (2016-2024) decklid release 2 ajar switch Wiring diagram
This page shows the only wiring diagram for the component.decklid release 2 ajar switch, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram decklid release 2 ajar switch (1 of 1)
2.0L TURBO
ANT 1 RTN
ANT 1 SIG
ANT 2 RTN
ANT 2 SIG
ANT 5 RTN
ANT 5 SIG
ANT SIG
ANT UHF
BATTERY DISTRIBUTION UNIT
BLK WIRE
BODY CONTROL MODULE
BRK SIG 1
BRN WIRE
CAN C (+)
CAN C (+) PANEL LAMPS DRV
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
CTRL OUT
DECKLID RELEASE 2 AJAR SWITCH
DECKLID/LIFTGATE
DECKLID/LIFTGATE AJAR SW SENS
DK BLU WIRE
DK BLU/BLK WIRE
EXTERIOR LIGHTS SYSTEM STARTING/CHARGING SYSTEM
FUSE 36
FUSE 73
FUSED B (+)
FUSED B(+) SECURITY K LINE COMM
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/DK BLU WIRE
HANDLE SW RTN
HANDLE SW SNS
HOT AT ALL TIMES
IGN RUN/START
IGN RUN/START CTRL OUT
IGN SW SENS
LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
LF PASSIVE ENT
LF PASSIVE ENT HANDLE SW RTN
LF PASSIVE ENT HANDLE SW SENS
ORG/DK BLU WIRE
PANEL LAMPS DRV
PASSIVE ENT ANT 1 RTN
PASSIVE ENT ANT 1 SIG
PASSIVE ENT ANT 2 RTN
PASSIVE ENT ANT 2 SIG
PASSIVE ENT ANT 3 RTN
PASSIVE ENT ANT 3 SIG
PASSIVE ENT ANT 4 RTN
PASSIVE ENT ANT 4 SIG
PASSIVE ENT ANT 5 RTN
PASSIVE ENT ANT 5 SIG
PASSIVE ENTRY 1 ANTENNA
PASSIVE ENTRY 2 ANTENNA
PASSIVE ENTRY 5 ANTENNA
PASSIVE ENTRY ANT 4 RTN
RADIO FREQUENCY HUB MODULE (CENTER OF DASH)
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/YEL WIRE
REMOTE START ANTENNA
RF PASSIVE ENT
RF PASSIVE ENT HANDLE SW RTN
RF PASSIVE ENT HANDLE SW SNS
RIGHT FRONT EXTERIOR DOOR HANDLE SWITCH
RIGHT REAR DOOR
SIG
STARTING/CHARGING SYSTEM
VIO/GRN WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Passive entry circuit -> DECKLID RELEASE 2 AJAR SWITCH
