Alfa Romeo Giulia 952 (2016-2024) circuit board body control module Wiring diagram
This page shows the only wiring diagram for the component.circuit board body control module, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram circuit board body control module (1 of 1)
2.0L TURBO
BASE
BATTERY DISTRIBUTION UNIT
BLK WIRE
BRN WIRE
CAN C (+)
CAN IHS (-)
CIRCUIT BOARD BODY CONTROL MODULE
CLUSTER
COMPUTER DATA LINES SYSTEM
DECKLID RELEASE 2 SWITCH
DECKLID RELEASE SWITCH 1
DECKLID RELEASE SWITCH 2
DECKLID/ LIFTGATE REL DRV
DECKLID/ LIFTGATE SIG
DECKLID/ LIFTGATE SIG GND
DECKLID/LIFTGATE REL DRV
DK BLU WIRE
FSD B(+)
FUSE 38
FUSE 73
GND LIFTGATE UNLOCK DRV
GRN WIRE
GRY/DK BLU WIRE
HOT AT ALL TIMES
LIFTGATE DOOR LATCH
LIFTGATE UNLOCK DRIVER
LIFTGATE UNLOCK RELAY
PANEL LAMPS DIMM SW MUX
PREMIUM
RADIO FREQUENCY HUB MODULE
RED WIRE
RED/BLK WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Deck lid release circuit -> CIRCUIT BOARD BODY CONTROL MODULE
