Alfa Romeo Giulia 952 (2016-2024) backup lp feed Wiring diagrams
This page contains all the electrical diagrams for the component. backup lp feed, in which he is found in the car Alfa Romeo Giulia 952 (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram backup lp feed (1 of 3)
2.0L TURBO
BACKUP LP FEED
BATTERY DISTRIBUTION UNIT
BLK WIRE
BRN WIRE
CAN C (+)
CAN IHS (-)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
FUSE 73
FUSED B (+)
GRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT LIFTGATE TAIL LAMP ASSEMBLY
RED WIRE
RED/BLK WIRE
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
SBW CYGNUS TCM MODULE
WHT WIRE
Go to component -> Backup lamps circuit -> BACKUP LP FEED
Wiring diagram backup lp feed (2 of 3)
AUXILIARY BANK SWITCH
BACKUP LAMPS CIRCUIT
BACKUP LP FEED
BLK WIRE
BLK/VIO WIRE
BRAKE LP
BRAKE LP SW OUTPUT
CAN IHS (-)
CENTER HIGH MOUNTED STOP LAMP
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
FUSE 53
FUSED B (+)
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
HAZARD IND CTRL
HAZARD SW SNS
HDLP SW SIG
HEADLAMP SWITCH
LEFT LIFTGATE TAIL LAMP ASSEMBLY
LEFT MULTI FUNCTION SWITCH
LH STOP LP DRV
ORG/ WIRE
PANEL LMPS
RED WIRE
RED/GRN WIRE
RH STOP LP DRV
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
SW OUTPUT
TURN SIG
WHT WIRE
WHT/BLK WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> BACKUP LP FEED
Wiring diagram backup lp feed (3 of 3)
2.0L TURBO
BACKUP LP FEED
BATTERY DISTRIBUTION UNIT
BLK WIRE
BRAKE LP SW OUTPUT
BRN/YEL WIRE
CAN IHS (-)
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/GRY WIRE
DK BLU/WHT WIRE
DRIVER OUTSIDE REAR- VIEW MIRROR
FUSE 1
FUSE 2
FUSE 3
FUSE 4
FUSE 51
FUSE 73
FUSED B (+)
GRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGNITION RUN/
IGNITION RUN/ START OUTPUT
LH STOP LP DRV
PASSENGER OUTSIDE REAR VIEW MIRROR
REAR FOG LP FEED
REAR POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RH STOP LP DRV
START OUTPUT
STOP/TURN SIG
TRAILER TOW CONNECTOR 1
TRAILER TOW CONNECTOR 2
TRAILER TOW LH
TRAILER TOW LH STOP/TURN SIG
TRAILER TOW MODULE (LEFT REAR OF VEHICLE)
TRAILER TOW RELAY
TRAILER TOW RH
TRAILER TOW RH STOP/TURN SIG
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Trailer tow circuit -> BACKUP LP FEED
