Alfa Romeo Giulia 952 (2016-2024) app sens gnd 1 app sens gnd 2 Wiring diagram
This page shows the only wiring diagram for the component.app sens gnd 1 app sens gnd 2, which is found in the car Alfa Romeo Giulia 952 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram app sens gnd 1 app sens gnd 2 (1 of 1)
2.0L TURBO
2.0L TURBO, 2.9L TURBO
2.9L TURBO
5 VOLT SPLY
5 VOLT SPLY 5 VOLT SPLY 2
5 VOLT SPLY 5 VOLT SPLY 2 5 VOLT SPLY
5 VOLT SPLY TP 2 SIG
ACCELERATOR PEDAL POSITION SENSOR
ADAPTIVE CRUISE CONTROL MODULE
APP SENS GND 1 APP SENS GND 2
APP SENS GND 2 APP SENS GND 1
APP SIG (1)
APP SIG (2)
AUXILIARY POWER DISTRIBUTION CENTER ASSEMBLY
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN C (+)
CLUSTER
COMPUTER DATA LINES SYSTEM
DK BLU/GRN WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
ETC MTR
ETC MTR (+) 5 VOLT SPLY
ETC MTR (-) TP SENS RTN
FRONT POWER DISTRIBUTION CENTER ASSEMBLY
FUSE 1
FUSE 84
FUSED B (+)
GRN WIRE
GRN/VIO WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
IGN (RUN)
OUTPUT
POWERTRAIN CONTROL MODULE
PRIVATE CAN (-)
RED WIRE
RED/GRN WIRE
S1026 (2.0L TURBO)
S1028 (2.0L TURBO)
TP 2 SIG
TP 2 SIG TP SENS RTN
TP SENS RTN
TP SIG
Go to component -> Cruise control circuit (1 of 2) -> APP SENS GND 1 APP SENS GND 2
