Acura TSX II (2008-2014) st rly coil Wiring diagram
This page shows the only wiring diagram for the component.st rly coil, which is found in the car Acura TSX II (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram st rly coil (1 of 1)
1 2 3 PNK WIRE
ANTENNA IN
ANTI-THEFT SYSTEM
BATTERY
BATTERY FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
COMBINATION LIGHT SWITCH CONNECTOR
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX 1 (UNDER LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ELD UNIT
FUSE
FUSE 4
GND B+
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IMMOBILIZER KEYLESS CONTROL UNIT (UNDER STEERING COLUMN COVER)
IMMOBILIZER KEYLESS CONTROL UNIT CONNECTOR
JUNCTION CONNECTOR
LT BLU WIRE
LT GRN WIRE
MULTI FUSE 1
MULTI- FUSE 3 IG MAIN FUSE
ORG/ WIRE
PNK 15 16 17 WIRE
PNK WIRE
RED WIRE
REMOTE STARTING CONTROL UNIT
REMOTE STARTING CONTROL UNIT GROUND
REMOTE STARTING CONTROL UNIT IN-LINE FUSE
RLY GND B-CAN LO B-CAN HI IMMOBILIZER SIG K-LINE
SCS
SHIFT LOCK SOLENOID
ST RLY COIL
STARTER CUT RELAY
STARTER MOTOR
STARTER SOLENOID STARTER REMOTE STARTING SYSTEM ANTENNA
TRANSMISSION RANGE SWITCH (UNDER AUTOMATIC TRANSMISSION)
UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
WIPER/WASHER SWITCH CONNECTOR
YEL WIRE
Go to component -> 2.4l, remote starting circuit (1 of 2) -> ST RLY COIL
